iQ. Inductor Equalizer

The sweetest parametric EQ

Inductors affect the sound in a beautiful way. They can saturate just like transformers do.

Precise & All stepped control. Not your grandpa’s EQ.

IGS IQ Equalizer is a modern application of the noble sound of analog equalizers. This very precise, parametric equalizer works great on every stage of production. It can add marvelous color to the signal, while maintaining the whole character of the original sound. This is a unique phenomenon possible only with analog processing. As opposed to digital eq it maintains neutrality and clarity on every setting. The simultaneous boosting and cutting of similar frequencies are the core secret of this device.

This is the typical effect of analog filters in the audio path. Most of the sound correction is in micro-manipulation. The frequency range is divided into 4 bands: Sub, Bass, Mid, High. In every band the frequency and boost/cut level can be set.

Finally an inductor EQ with the full, precise control engineers have been waiting for

The frequency range is divided into 4 bands: Sub, Bass, Mid, High, allowing you to control the frequency, boost/cut, bandwidth and bypass of each band! Now imagine two channels of that!!

  1. Videos
  2. Gallery
  3. Download
  4. Specification
  1. Basic features
    Q factor 0.3 - 6
    Boost/Cut Range +/- 10 dB
    Hard wire bypass Yes
    Input & Output
    Input Impedance (balanced) 10k ohm
    Output Impedance (balanced) 600 ohm
    Audio transformers Input & Output: IGS Custom transformers
    Operating Level +4dBu
    Max input level +22dBu
    Max output level +26dBu
    Frequency response 20 Hz - 20k Hz (+/-0.1 dB)
    Distortion (@ 20 Hz - 20 kHz)
    Crosstalk 102 dB
    Voltage 115/230V, 60/50Hz
    Power consumption 25W
    Power supply internal
    Packing box
    Dimensions 70x40x30 cm
    Shipping weight 4 kg
  2. Files
    IQ19 manual v1.pdf
